CompactFlash Card Connector - Express B Type - Push Push

  • CF Express Card Host Connector, B Type, 21Pin, R/A SMT Push Push, With Two Posts
    • Dimensions: 34.45x36.8x6.1(at maximun)
    • P/N: 139F40-NAATG310
  • Material & Finish:
    • Housing & Sloder: High Temperature Thermoplastic With Glass Fiber Filler, UL94V-0 Rated, Coloer In Black
    • Metal Shell: Stainles Steel SUS 304, Gold Flash Plated On Solder Area
    • Contact: Copper Alloy, 15u" Gold Plating On Contact Area, Tin Plated On Solder Area, Nickel Under Plated Overall
    • Spring: Paino thread
    • Crank: Stainless Rod SUS 304
    • Card Lock: Stainless Steel SUS 304
    Electrical SpecificationCurrent: DC 0.5A
    • Voltage: DC 5V
    • Dielectric Withstanding Voltage: 500V AC RMS For One Minute
    Operation Temperature: -25°C TO +85°C
